Oberton 15NXB1000

Cere mai multe informatii despre Oberton 15NXB1000 la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.

Preţ: 1.940,00 Lei

Fără TVA: 1.630,25 Lei

3 bucati in stoc

Producător: Oberton
Cod produs: 13823

Adaugă in Wishlist Compară produs

2 opinii Spune-ţi opinia

Etichete: Oberton 15NXB700 15NXB1000 difuzor profesional oberton woofer oberton difuzor 15 inch oberton oberton 15" woofer 15 inch difuzor 15 inch neodimium

Descriere Opinii (2)

Application: Power bass

The 15NXB1000 is neodymium bass loudspeaker designed to deliver high impact bass response, with exceptional high power capacity. It features 25 mm high sandwich voice coil, aluminium die cast frame with integrated triple aluminium demodulating rings and vented neodymium magnet structure. The massive heatsink improve the cooling of the magnet structure, which reduce power compression. This results in an incredible high efficient transducer for subwoofer applications, with the ability to handle high excursion with low distortion and reduced thermal power compression. It is suitable for tuned reflex or horn loaded enclosures for high level subwoofer applications.

SPECIFICATIONS		THIELE-SMALL PARAMETERS
Nominal Diameter Impedance Minimum Impedance Power Capacity AES ¹ Program Power ² Sensitivity Frequency Range Voice Coil Diameter Voice Coil Material Voice Coil Former Voice Coil Winding Depth Magnet Gap Depth Cone Material Basket Magnet Flux Density	15"/388 inch/mm 8 Ohm 7.23 Ohm 1000 W 2000 W (50-1000 Hz) 97 dB/W/m 38 - 1000 Hz 100 mm Copper Glassfiber 25 mm 14 mm Kevlar paper Die Cast Aluminium Neodymium 1.00 T	Resonance Frequency Mechanical Efficiency Factor (Qms) Electrical Efficiency Factor (Qes) Total Q (Qts) Equivalent Air Volume (Vas ) Diaphragm mass ind. airload (Mms) Voice Coil Resistance Re Effective Diagram Area (Sd) Peak Linear Displacement of Diaphragm (Xmax)* Mechanical Compliance of Suspension (Cms) BL Product (BL) V.C. Inductance at 1 kHz (Le)	38.34 Hz 8.75 0.293 0.283 105.50 litres 156.94 grams 5.23 Ohms 829.6 cm² ±9 mm 0.11 mm/N 25.99 T.m 1.98 mH
		MOUNTING INFORMATION
1. AES standard. Power is calculated on rated minimum impedance. Measurement is in 125 L box enclosure tuned 56 Hz using a 40-400 Hz band limited pink noise test signal applied continuously for 2 hours. 2. Program power is defined as 3db greater than AES Power Capacity. * Linear Mathematical Xmax is calculated as: (Hvc - Hg)/2 + Hg/4 where Hvc is the voice coil depth and Hg is the gap depth.		Overall Diameter Baffle Hole Diameter Number of Mounting Holes Bolt Circle Diameter Overall Depth Net Weight	388 mm 354 mm 8 eliptic 7x8 mm 370/372 mm 195 mm 8.1 kg
